1-1/8in Shank Two-circuit Four-position Metal Push Button Switch - Nickel Plated
- SKU:
- SW3587NP1
- MPN:
- ZE-117
- Function:
- Four Position
- Length:
- 0.875 (7/8in)
- Width:
- 0.750 (3/4in)
- Height:
- 1.812 (1-13/16)
- Type:
- Switch - Fixture - Push Button
- Color/ Finish:
- Polished Nickel
- Shaft Length:
- 1.125 (1-1/8in)
- Voltage (Max):
- 125V, 250V
- Certification:
- cRUus
Bulk discount rates
Below are the available bulk discount rates for each individual item when you purchase a certain amount
| Buy 10 - 99 | and pay only $2.25 each |
| Buy 100 or above | and pay only $2.10 each |
Description
1-1/8in Shank Two-circuit, Four-position, Metal, multi-level, Push Button Light Switch - Nickel Plated
Features
- Metal thread is 3/8 inch long.
- Ratings: 6A / 125VAC or 3A / 250VAC
- Black wire is "Line" power input. Red wire feeds Lamp #1. Blue wire feeds Lamp #2.
- Positions: Light #1, Light #2, Lights #1 & #2, Off.
