1/8ips Threaded Skirt with Shade Rest Shoulder Thermoplastic E-26 Lamp Socket with Shade Ring - White
- SKU:
- SOE26TP82W
- Material Type:
- Plastic
- Thread Size:
- 1/8ips - Female
- Size:
- Ring Diameter: 1.81in
- Width:
- 1.750 (1-3/4in)
- Height:
- 2.375 (2-3/8in)
- Bulb Base:
- E-26
- Type:
- Socket - E26 - Plastic
- Color/ Finish:
- White
- Function:
- Keyless
- Wired:
- No
- Voltage (Max):
- 125V
- Wattage (Max):
- 75W
- Damp:
- No
- Terminal Connection Type:
- Push Terminal
- Grounded:
- No
- Certification:
- CE, cRUus, ROHS
- Skirt Style:
- Threaded Skirt
Bulk discount rates
Below are the available bulk discount rates for each individual item when you purchase a certain amount
| Buy 10 - 99 | and pay only $2.70 each |
| Buy 100 - 249 | and pay only $2.50 each |
| Buy 250 or above | and pay only $2.35 each |
Description
E-26 White Threaded Skirt with Shade Rest Shoulder Thermoplastic Lamp Socket Includes 47mm ( 1-7/8in) Diameter Shade Ring and 1/8ips Threaded Cap with Locking Setscrew. UL Recognized
Features
- Push Terminal Wire Connections
- Spring type for Rigid and Flexible Cables.
- Lamp Socket Rated Maximum 660W, 250V. 150 Degree
- Socket can be Mounted using Screw Mounting Holes or included 1/8ips Female Threaded Cap.
- Dual Push Terminal Wire Connections for Daisy Chain Wiring.
